Armor Plates
Ch.Paisarn armor plates are engineered to deliver certified hard armor protection from Level III to Level IV — designed, manufactured, and tested in-house to stop the most demanding ballistic threats your operation may face.
Your Options
Ch.Paisarn armor plates are certified in compliance with NIJ 0101.06, NIJ 0101.07, and Thai Ministry of Defense ballistic standards — engineered to deliver reliable protection across a range of high-velocity and armor-piercing threats.
Option 1
NIJ Level III
Ballistic Plate Level III:
Bullet Protection
7.62x51 mm FMJ, 7.62x39 mm MSC, 5.56x45 mm (M193)
Option 2
NIJ Level III+
Ballistic Plate Level III+:
Bullet Protection
7.62x51 mm FMJ, 7.62x39 mm MSC, 5.56x45 mm (M193), 5.56x45 mm (M855)
Option 3
NIJ Level IV-
Ballistic Plate Level IV-:
Bullet Protection
7.62x51 mm FMJ, 7.62x39 mm MSC, 5.56x45 mm (M193), 5.56x45 mm (M855), 5.56x45 mm (M855A1), 7.62x39 API
Option 4
NIJ Level IV
Ballistic Plate Level IV:
Bullet Protection
7.62x51 mm FMJ, 7.62x39 mm MSC, 5.56x45 mm (M193), 5.56x45 mm (M855), 5.56x45 mm (M855A1), 7.62x39 API, 7.62x63 AP, 7.62x54 R API
Standards & Compliance
Every Ch.Paisarn armor plate is manufactured and tested in-house to meet the requirements of international and Thai national ballistic protection standards.
Compliance
NIJ Compliance
All Ch.Paisarn armor plates are certified in compliance with NIJ Standard 0101.06 and NIJ Standard 0101.07 — the international benchmark for ballistic resistance testing of hard armor plates against high-velocity and armor-piercing threats.
Backface Signature (BFS)
All plates comply with NIJ backface signature requirements — with BFS less than 44mm — reducing blunt force trauma transfer to the wearer and ensuring safety and comfort during ballistic impact events.
Certified Protection Across Every Mission Threat.
| NIJ 0101.06 Classification | Test Ammunitions | Max. Weight (kg.) | Material *Sic **B4C | |
|---|---|---|---|---|
| Standard | Premium | |||
| Level III |
| 1.2 | 0.90 | UHMWPE |
| 1.33 | 0.98 | ||
| Level III ++ |
| 1.80* | 1.35** - 1.45** | UHMWPE + Ceramic (Sic * / B4C** ) |
| Level IV- |
| 2.30* | 1.80** | UHMWPE + Ceramic (Sic * / B4C** ) |
| Level IV |
| 2.35** / 2.50* | 2.10** | UHMWPE + Ceramic (Sic * / B4C** ) |
Built to Your Specification
Every unit has different requirements. We work directly with agencies and procurement teams to configure the right plate solution — from material grade and plate geometry to surface finish and identification markings. Our team manages the entire process in-house, from design through to final inspection. Please specify your requirements when submitting your procurement inquiry
Step 1
Materials
UHMWPE Core
The foundation of every Ch.Paisarn plate — providing high ballistic resistance and multi-hit capability at low weight. Sourced from certified global manufacturers including Dyneema®.
Ceramic Composite
Integrated with the UHMWPE core for Level III++ and above — engineered to defeat high-velocity and armor-piercing threats that require ceramic reinforcement.
Custom Material Sourcing
For agencies with specific performance or operational requirements, our team works directly with procurement officers to source and configure the right material specification for your mission.
Step 2
Covering Materials
Concealable Armor
Fully customizable covering materials selected for durability, moisture resistance, and breathability to suit specific tactical environments or weight requirements.
Environmental Resilience
Specialized options engineered to maintain structural integrity and performance in harsh climates and extreme operational conditions.
Mission-Specific Aesthetics
Complete control over design, color, and camouflage patterns to ensure seamless integration with uniforms and team requirements.
Step 3
Cutting Materials
Size
Standard plates are supplied at 25 × 30 cm — engineered to provide an optimal balance of coverage and mobility for general applications. Custom dimensions are available on request, including side plate configurations for extended coverage.
Curvature
Available in Single Curved and Multi-Curved profiles — each designed to conform to the body's natural contours for a secure and comfortable fit during extended field operations.
Cut Shape
Four standard cut shapes are available to match your carrier system and operational requirement — Shooter Cut for optimized shoulder mobility, Full Plate for maximum torso coverage, SAPI Cut for compatibility with standard military carrier systems, and Swimmer Cut for enhanced upper arm mobility.
Trauma Reduction
Supporting materials are available to reduce blunt force trauma transfer to the wearer upon ballistic impact — integrated as an additional layer within the plate assembly.
Plate Marking & Identification
Plates can be marked or screen-printed to your unit's specifications — including strike face markings, threat protection level indication, unit identification, warning labels, and custom branding.
